Chief ConnexSys Adjustable Wall Mount, For Monitors 42-80", Black, Height Adjustable, 1 Display(s) Supported
SKU
INGMUU8168
by Chief
$754.72 /EACH
Delivered in 2-4 business days
In stock
Only 10 left
Category: Monitor Mounts & Stands
Chief's ConnexSys Video Wall Mounting System solves common video wall challenges of speed, alignment, serviceability and rigidity. The ConnexSys Video Wall Mounting System provides the ability to level each row once by using strut channel to connect multiple mounts together with a simple-to-install system that can handle the largest requirements
| Additional Information | SPEED; Hang units on a single strut channel for quick row leveling;; No need for horizontal spacers; Vertical measurement is simply the height of the display to the next rail; Compatible with most 1-5/8" sizes of channel strut; Reduces installation time - especially for XL and recessed configurations; Tool-free ClickConnect latching secures displays; PowerZone provides 6 points of adjustment in one easy-to-access location at the top of the mountALIGNMENT; PowerZone Adjustments;; Height adjustment 1" on each interface; Tilt adjustment at single pivot point, protects displays from twisting; Depth can be set between 4" and 7.4" from the wall, providing a range of "home positions" ideal for recessed installations;; Both sides adjust independently, compensating for imperfections in the wall; Walls can be out of alignment by up to 2" (horizontally); 3 levels of lateral adjustment; Mount left/right along rail; Interface left/right along mount; Lock in lateral guide for fine-tune adjustment using turn knobs, protecting screens from potential collisionsSERVICEABILITY; RapidDraw Display Release;; Cord release system gently and remotely pops any screen out for easy access and can be extended 13.4" for service; Protects displays by not requiring an aggressive push to release/pop-out; Releases only on demand, preventing accidental pop-outs; Cord can be set up to pull for release from any 90 degree angle; Kickstand provides 20 degrees of bottom tilt accessRIGIDITY; Rigid frame keeps displays where you set them, even after extending for service; Adjustable home depth position locks screens in place to maintain alignment despite accidental bumps/pushes |
|---|---|
| Brand Name | Chief |
| Country of Origin | China |
| Depth | 4" |
| Device Supported | Flat Panel Display |
| Features | Adjustable Depth |
| Features | Lateral Adjustment |
| Features | Leveling System |
| Features | Lockable |
| Features | Tilt |
| Height | 21.8" |
| Manufacturer Part Number | LVS1U |
| Manufacturer | Legrand Group |
| Maximum Adjustable Depth | 7.40" |
| Maximum Adjustable Height | 1" |
| Maximum Adjustable Width | 13.40" |
| Maximum Load Capacity | 150 lb |
| Maximum Screen Size Supported | 80" |
| Minimum Screen Size Supported | 42" |
| Mounting Pattern | 200 x 100 |
| Mounting Pattern | 700 x 400 |
| Number of Displays Supported | 1 |
| Product Color | Black |
| Product Line | ConnexSys |
| Product Model | LVS1U |
| Product Name | ConnexSys Video Wall Landscape Mounting System with Rails |
| Product Type | Wall Mount |
| Width | 35.5" |
| UPC | 841872161150 |
|---|---|
| Weight (lbs) | 43.2000 |
| MPN | LVS1U |
| Brand | Chief |
