Buildex Tapcon 3030 Concrete Screw Anchor, 3/16 in Dia, 2-1/4 in L, Stainless Steel, Climaseal
SKU
ORG7067283
$30.89 /BOX
Delivered in 2-4 business days
Out of stock
- Fast installation, just drill a hole and drive an anchor
- Replaces small diameter expansion anchors, plugs and screws in light to medium duty applications
- No need to pre-spot holes and no inserts are required
- Reversible and removable, can be installed close to an edge
- Compatible for use in ACQ treated wood
- 3/16 in Dia has a 1/4 in slotted hex washer head (HWH)
- Climaseal coating is standard on all Tapcon anchors to provide extended corrosion resistance
- Advanced Threadform Technology cuts into masonry materials for greater pullout values
- Nail-type point guides the anchor into the pre-drilled hole and excellent for wood to concrete applications
- For back-lighting, border lighting, cove lighting, edge lighting, path and contour marking
About Us:
Fast Shipping
62 warehouses nationwide
20 Years
Experience
Experience
Trusted since 2005
Category: Screws
The original masonry anchor that cuts its own threads into concrete, brick or block. Maximum performance is achieved because the Tapcon anchor, the condrive installation tool and the carbide-tipped Tapcon drill bits are designed to work as a system. It is essential to use the condrive tool and the correct drill bit to assure consistent anchor performance.
| Color | Blue |
|---|---|
| Diameter | 3/16in |
| Drill Size | 5/32 x 4-1/2in |
| Finish | Climaseal |
| Fixture Thickness | 1/2 to 1-1/4in |
| Head Type | Slotted Hex Washer |
| Length | 2-1/4 |
| Material | Stainless Steel |
| Minimum Embedment Depth | 1in |
| Shear Strength | 400 to 730lb |
| Tensile Strength | 220 to 340lb |
| Brand | Buildex Tapcon |
|---|---|
| Weight (lbs) | 1.3100 |
| UPC | 774463303007 |
| MPN | 3030 |
