Buildex Tapcon 3270 Concrete Screw Anchor, 1/4 in Dia, 4 in L, Stainless Steel, Climaseal
SKU
ORG7067309
$62.75 /BOX
Delivered in 2-4 business days
Out of stock
- Fast installation, just drill a hole and drive an anchor
- Replaces small diameter expansion anchors, plugs and screws in light to medium duty applications
- No need to pre-spot holes and no inserts are required
- Reversible and removable, can be installed close to an edge
- Compatible for use in ACQ treated wood
- 1/4 in Dia has a 5/16 in slotted hex washer head (HWH)
- Climaseal coating is standard on all Tapcon anchors to provide extended corrosion resistance
- Advanced Threadform Technology cuts into masonry materials for greater pullout values
- Nail-type point guides the anchor into the pre-drilled hole and excellent for wood to concrete applications
- For securing electrical junction boxes, conduit clips, exterior insulation systems, HVAC strapping, plywood backer boards, wood headers, furring strips to masonry
Category: Screws
The original masonry anchor that cuts its own threads into concrete, brick or block. Maximum performance is achieved because the Tapcon anchor, the condrive installation tool and the carbide-tipped Tapcon drill bits are designed to work as a system. It is essential to use the condrive tool and the correct drill bit to assure consistent anchor performance.
| Color | Blue |
|---|---|
| Diameter | 1/4in |
| Drill Size | 3/16 x 5-1/2in |
| Finish | Climaseal |
| Fixture Thickness | 2-1/4 to 3in |
| Head Type | Slotted Hex Washer |
| Length | 4 |
| Material | Stainless Steel |
| Minimum Embedment Depth | 1in |
| Shear Strength | 620 to 1000lb |
| Tensile Strength | 250 to 500lb |
| Brand | Buildex Tapcon |
|---|---|
| Weight (lbs) | 3.5100 |
| UPC | 774463327003 |
| MPN | 3270 |
