Cooper Industries 7501V-JP-C Standard Grade Decorator Switch, 15 A, 120/277 VAC, Toggle Actuator, Quiet Action
SKU
ORG9233495
$37.60 /PACKAGE
Delivered in 2-4 business days
Out of stock
- Convenient, built-in, no 12 and no 14 wire strippers
- No 12 and no 14 push-in terminals facilitate installation
- Redesigned mechanism for positive actuation and quiet operation
- Slotted, Phillips, and Robertson Tri-combo screw heads offer greater installation flexibility
- Longer and wider strap for easier mounting
- Strap rigidly bound to the backbody for improved structural integrity
- Easy access to no 8 ground screw
- A stippled ground tab helps hold the wire from pulling out when installed
- Virtually unbreakable ultrasonically welded top and backbody for optimal structural durability
- Backwire clamps on side terminals make wiring easier
About Us:
Fast Shipping
62 warehouses nationwide
20 Years
Experience
Experience
Trusted since 2005
Category: Home Electrical & Lighting
15A, 120/277 V AC. Longer wider metal mounting strap to eliminate floating on drywall. Built in wire strippers for #12 and #14 wire. Cam action switch mechanism insures quiet switch action and consistent paddle height. Interlocking mounting strap and d
| Series | 7501 |
|---|---|
| Type | Standard Grade |
| Voltage Rating | 120/277VAC |
| Suitable for Use With | Fluorescent Lighting Fixtures |
| Amperage Rating | 15A |
| Action | Quiet |
| Material | Thermoplastic |
| Number of Poles | 1 |
| Actuator | Toggle |
| Terminal Type | Push and Back Wire |
| Standards | cULus Listed, UL20 E18704/7504 |
| Usage | For New Home Construction, Apartments and Condos, Residential Upgrades and Renovations, Retail Locations, Banks and Brokerage Firms, Business Offices/Conference Rooms, Medical and Dental Practices, Hotels and Resorts |
| Temperature Rating | -20 TO 60deg C |
| Overall Length | 4.19 |
| Overall Width | 1.44 |
| Overall Depth | 0.97in |
| Download PDF File |
| Brand | EATON WIRING DEVICES |
|---|---|
| Weight (lbs) | 0.1500 |
| UPC | 032664643576 |
| MPN | 7501V-JP-C |
