Philips ICN2S40N Electronic Electronic Ballast, 120 - 277 VAC, 0.26 - 0.62 A, Rapid Start, 0.85 - 0.95 Ballast, 2 40 W

SKU
ORG0044024
$35.55 /EACH
Out of stock

Advance Centium Lamp Ballast, Electronic, Series: ICN-2S40-N35M, 120/277 V, 72 W, 0.62 - 0.26 A, 50/60 Hz, Fluorescent Lamp, T12 Lamp Base, 40 W Lamp, 2 Lamps, 0.85, Rapid Start, >0.9, 10 - 50 deg F Minimum, NEMA 410 Enclosure, 25 deg F, 1 in Overall Height, 1.3 in Overall Width, 9-1/2 in Overall Length, Aluminum, White Painted, Maximum THD <10%


SeriesAdvance, Centium
TypeElectronic
Voltage Rating120 - 277VAC
Wattage72
Amperage Rating0.26 - 0.62A
Frequency Rating50/60Hz
Lighting TechnologySeries
Lamp TypeF40T12 Fluorescent, T12
Lamp Base TypeT12
Lamp Wattage40W
Number of Lamps2
Ballast Factor0.85 - 0.95
Start TypeRapid
Power Factor0.98
Minimum Starting Temperature50deg F
Enclosure TypeNEMA 410
Temperature Range70deg C
Overall Height1in
Overall Width1.31in
Overall Length9-1/2in
MaterialMetal
FinishWhite Painted
Includes36 in Violet and Gray Control Leads
StandardsCE Certified, CSA Certified, UL Listed, RoHS Compliant
Special Features18 AWG Solid Wire
UsageFor Outdoor Applications
Download PDF File
BrandAdvance
Weight (lbs)1.250000
UPC781087074879
MPNICN2S40N
