Siemens Q130 Circuit Breaker, Mini, 30 A, 1 -Pole, 120 V, Fixed Trip, Plug Mounting
SKU
ORG1627827
by Siemens
$38.15 /EACH
Delivered in 2-4 business days
Out of stock
About Us:
Fast Shipping
62 warehouses nationwide
20 Years
Experience
Experience
Trusted since 2005
Non-interchangeable trip. 120 VAC, 10,000 AIR. Will replace American Switch, Westinghouse Type BR, Bryant, Challenger, Sylvania, Crouse-Hinds, Murray, Frank Adams, General Electric (Full size only), General Switch, I-TE, Gould, Montgomery Ward and Sears. UL listed, HACR rated. 15 and 20 A UL listed for frequent switching applications, 120 VAC fluorescent lighting. 1 in per pole.
| Actuator Type | Magnetic Thermal |
|---|---|
| Current Rating | 30A |
| Dimensions | 1 in L x 3 in W x 3 in H |
| Frame Type | QP |
| Interrupt Rating | 10kA |
| Mounting Type | Plug |
| Number of Phases | 1 |
| Number of Poles | 1 |
| Operating Frequency | 50/60Hz |
| Operating Temperature | 40deg C |
| Terminal Type | Lug |
| Trip Type | Fixed |
| Type | Mini |
| Voltage Rating | 120V |
| Wire Size | 14 to 6AWG |
| Brand | Siemens |
|---|---|
| Weight (lbs) | 0.3200 |
| UPC | 662862003898 |
| MPN | Q130 |
