Siemens Q230 Circuit Breaker, Mini, 30 A, 2 -Pole, 120/240 V, Fixed Trip, Plug Mounting
SKU
ORG1627348
by Siemens
$55.38 /EACH
Delivered in 2-4 business days
Out of stock
About Us:
Fast Shipping
62 warehouses nationwide
20 Years
Experience
Experience
Trusted since 2005
Molded case with non-interchangeable trip. Will replace American Switch, Westinghouse Type BR, Bryant, Challenger, Sylvania, Crouse-Hinds, Murray, Frank Adams, General Electric (full size only), General Switch, I-T-E, Gould, Montgomery Ward and Sears. UL listed. HACR rated. 120/240 VAC; 10,000 AIR. 1 in per pole (2 in total).
| Actuator Type | Magnetic Thermal |
|---|---|
| Current Rating | 30A |
| Dimensions | 3 in L x 3 in W x 2 in H |
| Frame Type | QP |
| Interrupt Rating | 10kA |
| Mounting Type | Plug |
| Number of Phases | 1 |
| Number of Poles | 2 |
| Operating Frequency | 50/60Hz |
| Operating Temperature | 40deg C |
| Terminal Type | Lug |
| Trip Type | Fixed |
| Type | Mini |
| Voltage Rating | 120/240V |
| Wire Size | 14 to 6AWG |
| Brand | Siemens |
|---|---|
| Weight (lbs) | 0.5500 |
| UPC | 662862004154 |
| MPN | Q230 |
