StarTech.com Dual M.2 SATA Adapter with RAID
Delivered in 2-4 business days
- Install two M.2 NGFF SSDs into a single 2.5? SATA bay and build a powerful RAID array
- Supports RAID 0, RAID 1, spanning, or JBOD
- Add M.2 SSD performance to any computer system by converting M.2 to SATA
- Protect your M.2 (NGFF) SSDs in any 2.5in application with enclosed housing
- Supports TRIM to help ensure stable performance of your M.2 SSDs
- Supports SATA I/II/III (up to 6Gbps)
- 2.5in SATA form factor housing
- Broad compatibility with support for the most common SATA M.2 SSDs (2230, 2242, 2260, 2280)
- Not compatible with M.2 NVMe or AHCI PCI-Express SSDs
Boost your system performance by enhancing the capacity, speed and security of your data storage. This two-drive M.2 to SATA adapter lets you install two M.2 solid-state drives in a single 2.5" drive bay and configure a powerful RAID array. Build a RAID array to enhance system performance The dual M.2 to SATA adapter supports multiple RAID modes (RAID 0, 1, BIG) helping you to achieve greater SSD capacity or data redundancy, depending on your selected RAID mode. The SSD adapter also supports non-RAID operation (JBOD) when paired with a port-multiplying SATA controller, so both drives can be used independent of one another. Maximize file transfer speeds The dual SSD adapter lets you utilize the full potential of your SATA III controller. Using M.2 SSDs in place of a platter drive reduces your data transfer bottlenecks and gives you file transfer speeds of up to 6 Gbps. M.2 SSDs also save you money by reducing your power consumption over regular platter drives. The M.2 NGFF SATA RAID adapter also provides TRIM support to enhance the stability and performance of your M.2 NGFF SSDs. Get dependable drive protection The M.2 to SATA adapter features an enclosed housing that helps protect your NGFF (Next Generation Form Factor) SSD. The added protection gives you peace of mind when you are using your M.2 drives in applications that require an added level of durability such as hot-swap drive bays, or external SATA docking stations. The 25S22M2NGFFR is backed by a StarTech.com 2-year warranty and free lifetime technical support.
| Brand Name | StarTech.com |
|---|---|
| Certifications & Standards |
|
| Country of Origin | Taiwan |
| Depth | 3.9" |
| Environmental Certification | RoHS |
| Environmental Certification | WEEE |
| Environmentally Friendly | Yes |
| Height | 0.3" |
| Limited Warranty | 2 Year |
| Manufacturer Part Number | 25S22M2NGFFR |
| Manufacturer | StarTech.com |
| Package Contents |
|
| Packaged Quantity | 1 |
| Product Color | Black |
| Product Color | Silver |
| Product Name | Dual M.2 NGFF SATA Adapter With RAID |
| Product Type | M.2 to SATA Adapter |
| TAA Compliant | Yes |
| Weight (Approximate) | 1.90 oz |
| Width | 2.8" |
| UNSPSC | 43211600 |
| Download PDF File |
| Brand | StarTech.com |
|---|---|
| Weight (lbs) | 0.2500 |
| UPC | 065030863315 |
| MPN | 25S22M2NGFFR |
| Prop65 Warning | WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov. |
