StarTech.com Single Mode SC Fiber Ethernet Media Converter - 1000BASE-LX Gigabit Fiber Optic to Copper Bridge - 10/100/1000 Network 10km
Delivered in 2-4 business days
- Converts and extends a Gigabit Ethernet (1000 Mbps) network up to 10 km over single-mode fiber on 1000BASE-LX networks
- Provides a cost-effective Ethernet to fiber/copper to fiber link
- Supports a maximum distance of 10 km over single mode duplex fiber optic cable (SC connection)
- Compact design and wall mountable
- Non-blocking full wire-speed forwarding rate
This fiber media converter converts and extends a Gigabit Ethernet (1000 Mbps) network up to 10 km over single-mode fiber on 1000BASE-LX networks. Extend your GbE network cost-effectively The fiber media converter provides a cost-effective way to transparently convert copper to fiber, or fiber to copper, for connecting remote sub-networks to larger fiber-optic networks. Providing both SC fiber and RJ45 Ethernet ports, it integrates easily into a wide range of Gigabit Ethernetnetwork infrastructures.The RJ45 port supports triple-speed (10/100/1000 BASE-T) auto-negotiation. Reliable and scalable network connectivity Supporting a maximum single-mode fiber cable distance of up to 10 km (6.2 mi.), the media converter delivers a simple and reliable solution for connecting Gigabit Ethernet networks to remote locations, while ensuring solid network performance. It provides optimum network scalability for connecting two or more Ethernet network nodes, for instance, connecting two buildings on the same campus or facility. The media converter also delivers high-speed bandwidth to meet the increasing demands of large-scale workgroups that require expansion of a Gigabit Ethernet network. The MCMGBSCSM10 is backed by a StarTech.com 2-year warranty and free lifetime technical support.
| Brand Name | StarTech.com |
|---|---|
| Country of Origin | Taiwan |
| Depth | 2.8" |
| Environmental Certification | REACH |
| Environmental Certification | RoHS |
| Environmental Certification | WEEE |
| Environmentally Friendly | Yes |
| Ethernet Technology | Gigabit Ethernet |
| Fiber Mode Supported | Single-mode |
| Fiber Optic Wavelength | 1310 nm |
| Form Factor | Wall Mountable |
| Height | 1" |
| Limited Warranty | 2 Year |
| Manufacturer | StarTech.com |
| Manufacturer Part Number | MCMGBSCSM10 |
| Maximum Distance Supported | 6.21 Mile |
| Media Type Supported | Optical Fiber |
| Media Type Supported | Twisted Pair |
| Network (RJ-45) | Yes |
| Network Technology | 1000Base-LX |
| Network Technology | 1000Base-T |
| Network Technology | 100Base-LX |
| Network Technology | 10Base-T |
| Number of Network (RJ-45) Ports | 1 |
| Number of SC Ports | 1 |
| Package Contents |
|
| Packaged Quantity | 1 |
| Plug/Connector Type | Type N |
| Power Consumption | 10 W |
| Power Source | AC Adapter |
| Product Name | Gigabit Ethernet to SC Fiber Media Converter - 1000Base-LX - Single-mode - 10 km |
| Product Type | Transceiver/Media Converter |
| SC Port Type | Duplex |
| TAA Compliant | Yes |
| Total Number of Ports | 2 |
| Weight (Approximate) | 6.90 oz |
| Width | 4.1" |
| Download PDF File |
| Brand | StarTech.com |
|---|---|
| Weight (lbs) | 1.1600 |
| UPC | 065030878241 |
| MPN | MCMGBSCSM10 |
