StarTech.com 2 Port Dual Input VGA Matrix Splitter - Video Switch - 2 ports
SKU
STCST222MX
by StarTech.com
$72.81 /EACH
Delivered in 2-4 business days
Out of stock
- Allows two computers to provide video input to display on 2 different monitors
- Allows you to switch video input signals on both monitors
- Works with VGA, SVGA, XGA and Multisync monitors
- High video bandwidth (250 Mhz) provides resolution of up to 1920 x 1440 pixels
- Daisy chainable for use with more than 8 monitor hookups
- Equipped with easy to use front panel selection buttons
Category: Cables & Adapters
This Dual Input VGA Matrix Splitter not only provides optimal convenience and control, but also exceptional video quality on multiple monitor configurations. This 2 port VGA Matrix Video Splitter allows you to input two distinct video signals that can be switched for viewing on either or both of the two connected monitors at the push of a button. Plus, multiple VGA Matrix video splitters can be connected together (cascaded), allowing you to quickly switch between up to eight displays. The VGA Matrix splitter is broadly compatible with industry video standards, including VGA, SVGA, XGA and multisync monitors, and provides exceptional video bandwidth (250MHz) and a maximum resolution of 1920 x 1440 pixels.
| Packaged Quantity | 1 |
|---|---|
| Connectivity Technology | Cable |
| Number of Input Devices Supported | 2 |
| Device Supported |
|
| Number of Displays Supported | 2 |
| Graphics Modes |
|
| Maximum Video Resolution | 1920 x 1440 |
| Maximum Video Bandwidth | 250 MHz |
| VGA In | Yes |
| VGA Out | Yes |
| Number of VGA Inputs | 2 |
| Number of VGA Outputs | 2 |
| Maximum Operating Distance | 210 ft |
| Input Voltage | 7.5 V DC |
| Product Color | Gray |
| Height | 1.7" |
| Width | 3" |
| Depth | 5.1" |
| Weight (Approximate) | 15.49 oz |
| Package Contents |
|
| Additional Information |
|
| Certifications & Standards |
|
| Environmentally Friendly | Yes |
| Environmental Certification |
|
| Limited Warranty | 2 Year |
| Download PDF File |
| Brand | StarTech.com |
|---|---|
| Weight (lbs) | 1.4000 |
| UPC | 065030805230 |
| MPN | ST222MX |
